The Morgan Plus Four Plus Sports Car

                                               Morgan Plus Four Plus

                                        Follow Me on Facebook

                                           from Classic to Modern


     To stimulate sales of Morgan sports cars, it was decided to venture into an area not previously considered by the company - glassfibre.

     Furthermore, the new model would no longer incorporate a wooden frame made of Ash, as had been the case in all previous models.

     The body styling finally agreed was based upon a fixed head coupe design, with additional touches of luxury including, for the first time on a Morgan, wind up windows, a curved windscreen, and locks on the boot.

     Without doubt, this was a bold move by the company, since it represented a complete departure from the philosophy of the previous half century.

     The prototype was subjected to rigorous testing, including entry into a number of trials, in order to assess its dependability and driving characteristics.

     Consequently, the Plus Four Plus was introduced to the market, in 1963, at the Earl's Court Motor Show, and backed up by an advertising campaign.

     This was the first fixed head coupe that Morgan had built in its long and illustrious history.

     The body styling was fairly advanced for its time, and consisted of a glassfibre body on a Plus 4 chassis, which had been duly strengthened.

     In general terms it was, mechanically, not unlike the Morgan Plus 4, and its specification included:

  • Powered by a straight, 4-cylinder, pushrod, 2.1 litre Triumph TR4A engine, developing 105 bhp at 4750 rpm
  • Compression ratio of 9:1
  • Five bearing crankshaft
  • Four speed manual gearbox with synchromesh on the top three gears
  • Two SU carburettors
  • Same suspension as the Plus 4, with a solid axle and leaf springs at the rear, but with stiffened coils springs at the front
  • Disc brakes at the front, drums at the rear, but no servo assisted braking

     As a result of the hard suspension, there was minimum body roll even when subjected to demanding driving.

Technical Data                            Plus 4 Plus        Plus 4
Production:                                 1964-1967        1958
Engine cc                                         2138             1991
Cylinders, bhp                                4, 104            4, 90
Top Speed mph                                110               100
0-60 mph, secs                               12.0              13.3
Torque ft/lbs                                   128               120

     The two seater, fixed head body was made of fibreglass, which greatly reduced the cars' overall weight.

     As a result of its aerodynamic shape, the performance was slightly better than that of the Plus 4.

     Furthermore, due to the body styling, the interior space was increased which produced, amongst other things, ample leg room, even though it was a little noisy inside.

     Initial reaction from the market did not meet the company's expectations, possible due to the fact that it was such a departure from the accepted norm.

     Unfortunately, it did not appeal to the traditional customer of Morgan sports cars.

     In a most unexpected quirk of fate, although the market had, in reality, shunned the new car, sales of the existing models experienced a boost.

     This left the company in no doubt as to the most appropriate course of action to take.

     Accordingly, after a production run of three years in which only 26 units of the new model were built, the car was finally phased out.

     Following its demise, the company withdrew from producing such "out of character" models, and reverted back to its roots of building traditionally styled classic cars.

     Subsequent to the ending of production in 1967, the car was regarded, for some time, as not a true member of the Morgan family.

     However, time is a great healer, and the car is now regarded as highly desirable, not only for its advanced styling at that time, but also for the fact that it was, quite literally, a limited edition model.


                                                           .
